Product Summary
Item | Specification |
Nominal Capacity | 2800mAh (0.2C, 2.75V discharge) |
Minimum Capacity | 2700mAh(0.2C, 2.75V discharge) |
Charging Voltage | 4.3 ±0.03 V |
Nominal Voltage | 3.7V |
Charging Method | CC-CV (constant voltage with limited current) |
Charging Current | Standard charge: 1400mA / Rapid charge : 2800mA |
Charging Time | Standard charge : 3hours / Rapid charge : 2.5hours |
Max. Charge Current | 2600mA(ambient temperature 25℃) |
Max. Discharge Current | 5200mA(ambient temperature 25℃) |
Discharge Cut-off Voltage | 2.75V |
Cell Weight | 48.0g max |
Cell Dimension | Height : 65.00mm max Diameter : 18.40mm max |
Operating Temperature | Charge : 0 to 45℃ / Discharge: -20 to 60℃ |
