Product Summary

The HMC902 is a GaAs MMIC Low Noise Amplifier, which operates between 5 and 10 GHz. This self-biased LNA provides 20 dB of small signal gain, 1.6 dB noise figure, and output IP3 of +28 dBm, while requiring only 80 mA from a +3.5V supply. The P1dB output power of 16 dBm enables the LNA to function as a LO driver for balanced, I/Q or image reject mixers. The HMC902 also features I/Os that are DC blocked and internally matched to 50 Ohms for ease of integration into multi-chip-modules (MCMs). All data is taken with the chip in a 50 Ohm test fixture connected via 0.025 mm (1 mil) diameter with bonds of 0.31 mm (12 mils) length.

Features

IC AMP MMIC GAAS LN

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
HMC902LP3E
HMC902LP3E

IC AMP MMIC GAAS LN 16QFN
Data Sheet
0-1: $18.06
1-10: $16.74
10-25: $15.34
25-100: $14.29
100-250: $13.06
